Closed loop stepper motor 3 Nm NEMA 23 Servo Hybrid Encoder
$1,340.00
Closed Loop Stepper Motor 3Nm Nema23 Hybrid Encoder.
The standard series 2-phase stepper motor power stage offers balanced performance by high torque, low vibration and low noise. The PK series 2 phase stepper motor with encoder offer high torque and precise feedback capability.
MOTOR SPECIFICATION
- Number of phases:2
- Holding Torque:3Nm
- Rated Current:/phase:4.2A
- Phase resistance:0.82 ohms
- Inductance:3.6mH +/-20% 1KHz inductance
- Frame size:57x57 mm
- Body length:113 mm
- Shaft Diameter:8 mm
- Shaft length:37 mm
- Keyway shaft length:21mm
